Caterpillar

Caterpillar Model	Max. Pulling Force kg-F	Line Speed m/min	Belt Dimensions mm*mm	Cable Pressure Length mm	Max. Belt Spaces mm	Max. Clamping Force kN	Motor Power kW	Pulley Ø mm	Top/ Bottom Cylinder Quantity	Rollers Per Cylinder	Clamping Cylinders Ø mm	Tensioning Cylinders Ø mm
UMCAT1000	1000	300	120*20	1600	120	19	22	300	5	5	80	125
UMCAT1500	1500	160	150*20	1550	150	24	22	300	5	6	100	125
UMCAT2000	2000	120	150*20	2200	150	30	22	300	7	6	80	125
UMCAT2500	2500	100	180*20	2500	150	40	22	300	8	6	100	160
